katomax engine serial
KATOMAX serial generator set with power range :650~3000kva.Katomax engine brand is well known as it's large output power , high efficient, small size and durability.It is one of the most advanced engine manufacturers in the world.
- Specifications
- Inquiry
| Genset Model | Standby Power | Prime Power | KATOMAX Engine | open type | soundproof type | ||||
| KVA | KW | KVA | KW | Diemension（cm） | Weight（kgs） | Diemension（cm） | Weight（kgs） | ||
| Single Phase(230V) | |||||||||
| CPY-8GF-1 | 7.9 | 7.9 | 7.2 | 7.2 | YD380D | 115*78*91 | 365 | 168x80x105 | 630 |
| CPY-10GF-1 | 9.5 | 9.5 | 8.6 | 8.6 | YD385D | 115*78*91 | 480 | 168x80x105 | 630 |
| CPY-12GF-1 | 12.3 | 12.3 | 11.2 | 11.2 | YD480D | 115*78*91 | 490 | 168x80x105 | 630 |
| CPY-15GF-1 | 15 | 15 | 13.6 | 13.6 | YND485D | 150*90*98 | 505 | 184x80x105 | 750 |
| CPY-18GF-1 | 18.4 | 18.4 | 16.8 | 16.8 | YND490D | 150*90*98 | 650 | 184x80x105 | 800 |
| CPY-22GF-1 | 22 | 22 | 20 | 20 | Y495D | 181*95*102 | 690 | 195x80x105 | 900 |
| CPY-25GF-1 | 24.6 | 24.6 | 22.4 | 22.4 | Y4100D | 181*95*102 | 700 | 210*88*115 | 1000 |
| Three PhaGF-1e(230/400V) | |||||||||
| CPY-11GF | 11 | 8.8 | 10 | 8 | YD380D | 115*78*91 | 365 | 168x80x105 | 620 |
| CPY-12GF | 12.1 | 9.7 | 11 | 8.8 | YD385D | 115*78*91 | 480 | 168x80x105 | 650 |
| CPY-15GF | 14.9 | 11.9 | 13.5 | 10.8 | YD480D | 115*78*91 | 490 | 168x80x105 | 650 |
| CPY-18GF | 17.6 | 14.1 | 16 | 12.8 | YND485D | 150*90*98 | 505 | 184x80x105 | 750 |
| CPY-25GF | 23.1 | 18.5 | 21 | 16.8 | YND490D | 150*90*98 | 650 | 184x80x105 | 780 |
| CPY-30GF | 29.7 | 23.8 | 27 | 21.6 | Y495D | 181*95*102 | 690 | 195x80x105 | 830 |
| CPY-35GF | 33 | 26.4 | 30 | 24 | Y4100D | 181*95*102 | 700 | 210*88*115 | 900 |
| CPY-40GF | 41.3 | 33 | 37.5 | 30 | Y4105D | 181*95*102 | 770 | 210*88*115 | 950 |
| CPY-55GF | 55 | 44 | 50 | 40 | Y4102ZLD | 199*950*136 | 800 | 246*100*126 | 1000 |
| CPY-60GF | 60 | 48 | 55 | 44 | Y4105ZLD | 199*950*136 | 850 | 246*100*126 | 1100 |
| CPY-70GF | 70 | 56 | 63 | 50.4 | YD4EZLD | 199*950*136 | 995 | 246*100*126 | 1200 |
| CPY-88GF | 88 | 70.4 | 80 | 64 | Y4110ZLD | 199*950*136 | 1000 | 256*100*126 | 1300 |
| CPY-110GF | 110 | 88 | 100 | 80 | LR4M3L-D | 225*100*145 | 1035 | 296*110*165 | 1680 |
| CPY-165GF | 165 | 132 | 150 | 120 | LR6M3L-D | 240*100*170 | 1680 | 336*110*170 | 2070 |
| CPY-220GF | 220 | 176 | 200 | 160 | YM6H4L-D | 280*120*185 | 1730 | 391*133*210 | 2988 |
| CPY-275GF | 275 | 220 | 250 | 200 | YM6GF-14L-D | 295*120*185 | 2000 | 391*133*210 | 3093 |
| CPY-300GF | 300 | 240 | 275 | 220 | YM6GF-14LF-D | 310*120*185 | 2480 | 426*146*210 | 3627 |
| CPY-360GF | 360 | 288 | 325 | 260 | YM6GF-19L-D | 320*162*195 | 2850 | 426*162*230 | 3999 |
| CPY-412GF | 400 | 320 | 360 | 288 | YM6GF-19LF-D | 320*162*195 | 3400 | 426*162*230 | 4029 |
