CP6800iE
- Specifications
- Inquiry
| Engine | Model | CP6800iE |
| Max.Power(kW) | 5.5kw | |
| Rated Power | 5kw | |
| Rated Voltage(V) | 230V | |
| Rated Current(A) | 22Amp | |
| Type | 1-cylinder, 4-stroke,air cooled gasoline engine | |
| Displacement | 224CC | |
| Starting system( | Manual/Electircal/Remote start | |
| Lube oil capacity(L) | 0.6L | |
| Generator | Fuel oil tank volume (L) | 11L |
| Power Factor | 1 | |
| IP Grade | IP23M | |
| Insulation Grade | B | |
| Perforance Grade | G1 | |
| Quality Class | A | |
| NOISE at 7M (dB) | 60dB | |
| Logistic data | Net Weight(kg) | 39.5kgs |
| Packing Weight | 41kgs | |
| Dimension(LxWxH) | 620*430*600mm | |
| Packing size(LxWxH) | 645*450*610mm | |
| Load Qantity （20/40/40HQ） | 135/285/380 pcs |
